Diamond Segment Stone Cutter Tools
Description:
Specification:
| Segments for 300-800mm diamond saw blade | ||||||
| Diameter | Core Thickness (mm) | Segment Dimension (mm) | No. of Teeth | |||
| mm | inch | Length | Thickness | Height | ||
| 300 | 12" | 2.0/2.2 | 40 | 2.8/3.0 | 8/10/12/15 | 21 |
| 350 | 14" | 2.2/2.4 | 40 | 3.0/3.2 | 8/10/12/15 | 24 |
| 400 | 16" | 2.6/2.8 | 40 | 3.4/3.6 | 8/10/12/15 | 28 |
| 450 | 18" | 2.8/3.0 | 40 | 4.0/4.2 | 8/10/12/15 | 32 |
| 500 | 20" | 2.8/3.0 | 40 | 4.0/4.2 | 8/10/12/15 | 36 |
| 600 | 24" | 3.6 | 40 | 4.6 | 8/10/12 | 42 |
| 700 | 28" | 4 | 40 | 5.2 | 8/10/12 | 42 |
| 800 | 32" | 4.5 | 40 | 6.0 | 8/10/12 | 46/57 |
| Segments for 900-3500mm single/multi blades | ||||||
| Diameter | Core Thickness (mm) | Segment Dimension (mm) | No. of Teeth | |||
| mm | inch | Length | Thickness | Height | ||
| 900 | 36" | 5 | 22/24 | 6.0/6.6 | 12/13/15 | 64 |
| 1000 | 40" | 5.5 | 22/24 | 6.4/7.0 | 12/13/15 | 70 |
| 1200 | 48" | 6 | 22/24 | 7.4/8.0 | 12/13/15 | 80 |
| 1400 | 55" | 6.5 | 22/24 | 7.8/8.4 | 12/13/15 | 92 |
| 1600 | 64" | 7.2 | 22/24 | 8.4/9.0 | 12/13/15 | 108 |
| 1800 | 72" | 8 | 22/24 | 9.2/9.8 | 12/13/15/20 | 120 |
| 2000 | 80" | 8 | 22/24 | 9.5/10.5 | 12/13/15/20 | 128 |
| 2200 | 88" | 9 | 22/24 | 10.5/11.5 | 12/13/15/20 | 132 |
| 2500 | 110" | 9 | 22/24 | 11.5/12.5 | 12/13/15/20 | 140 |
| 3000 | 120" | 10 | 22/24 | 12.5/13.5 | 12/13/15/20 | 160 |
| 3500 | 140" | 10 | 22/24 | 13.5/14.5 | 12/13/15/20 | 180 |
*Other specifications are available upon request.
FAQ
Q1:Are you a factory or trading company?
A1:We are factory.
Q2:How can I know the quality?
A2:Try to make a trial, after you used our segments, then you will know the quality. According to your requirements, production of products what you want. Pls don't worry, we have 16 years of experience in diamond tools industry.
Q3:What about the minimum of quantity?
A3:Any quantity order is available.
Q4:How can I get the best suitable diamond segments?
A4:Provide to us more details about your stone and your diamond saw blade.We can give you advice.
Q5:What are your payment terms?
A5: The payment should be 100% T/T before shipment.
Q6:What could we do if we find your products can not run well?
A6:Please provide us the details data.We can analyze the possible reasons, try to find the problem, then tell you how to solve them.
Specification:
*250-800mm
| Diameter(mm) | Segment Size(mm) | Segment NO.(pcs/set) | Welding Method | Structure | ||
| Length | Width | Height | ||||
| 250 | 40 | 2.5 | 8/10 | 18 |
Silver Welding or Laser Welding |
Multi-Layer or No-Layer
|
| 300 | 40 | 3.2 | 8/10 | 21 | ||
| 350 | 40 | 3.2/3.4 | 8/10 | 24/25 | ||
| 400 | 40 | 3.6 | 8/10 | 28 | ||
| 450 | 40 | 4.0 | 8/10 | 32 | ||
| 500 | 40 | 4.2 | 8/10 | 36 | ||
| 550 | 40 | 4.4 | 8/10 | 38 | ||
| 600 | 40 | 4.6 | 8/10 | 42 | ||
| 700 | 40 | 5.0 | 8/10 | 50 | ||
| 725 | 40 | 5.5 | 8/10 | 50 | ||
| 800 | 40 | 5.2 | 8/10 | 46 | ||
*900-3500mm
| Diameter(mm) | Segment Dimension(mm) | Segment No. | Welding Method | Structure | ||
| Length | Width | Height | ||||
| 900 | 24 | 7.0/6.5 | 10/12/15/20 | 64 |
Silver Welding or Laser Welding |
Multi-Layer or No-Layer |
| 1000 | 24 | 7.0/6.5 | 10/12/15/20 | 70 | ||
| 1100 | 24 | 7.4/6.8 | 12/15/20 | 74 | ||
| 1200 | 24 | 7.5/7.0 | 12/15/20 | 80 | ||
| 1300 | 24 | 8.0/7.5 | 12/15/20 | 88 | ||
| 1350 | 24 | 8.4/7.7 | 12/15/20 | 88 | ||
| 1400 | 24 | 8.5/8.0 | 12/15/20 | 96 | ||
| 1600 | 24 | 9.0/8.7/8.4 | 12/15/20 | 108 | ||
| 1700 | 24 | 9.4/8.9/8.4 | 12/15/20 | 112 | ||
| 1800 | 24 | 9.5/9.0 | 12/15/20 | 120 | ||
| 2000 | 24 | 10.5/9.5 | 12/15/20 | 128 | ||
| 2200 | 24 | 11.5/10.5 | 12/15/20 | 132/136 | ||
| 2500 | 24 | 12/11.5/11 | 15/20/25/30 | 140 | ||
| 2700 | 24 | 12/11.5/11 | 15/20/25/30 | 140 | ||
| 3000 | 24 | 12.5/12/11.5 | 15/20/25/30 | 160 | ||
| 3500 | 24 | 13/12.5/12 | 15/20/25/30 | 180 | ||
